M5AtomController
小林 竜太
@ryotakobayashi
Controller capable of wireless communication by ESP-NOW and wired communication by UART serial
あなたは普段、どんなコントローラを使用していますか？PC用やゲーム用、いろいろあります。そして今ではそのほとんどは無線通信です。それはとても便利ですが問題もあります。例えば展示会場、混線して無線が繋がりません。そういう場合、気軽に無線と有線を切り替えたくなります。
What kind of controller do you usually use? There are many for PC and games. And now most of them are wireless. It's very convenient, but it has its problems. For example, at an exhibition hall, bad reception. 😩
この作品は、そういった問題を解決することができます。普段はESP-NOWで無線通信を行い、UART接続するだけですぐにシリアル通信へ切り替え可能です。これは多くのMakerをサポートするコントローラです。
This work can solve such problems. Wireless communication is usually performed with ESP-NOW, and it is possible to immediately switch to serial communication simply by connecting UART. This is a controller that supports many "Makers" 😃
| # | Part | Item | Qty | Link |
|
|
-- |
| :
: |
-- | | 1 | ATOM Matrix | ESP32 Development Kit | 1 | M5Stack , SwitchScience | | 2 | ATOM TailBAT | Battery | 1 | M5Stack , SwitchScience | | 3 | M5AtomControllerBoard | Circuit board | 1 | JLCPCB | | 4 | M5AtomControllerMain | 3D print parts | 1 | JLCPCB | | 5 | M5AtomControllerCover | 3D print parts | 1 | JLCPCB | | 6 | M5AtomControllerCrossKey | 3D print parts | 1 | JLCPCB | | 7 | M5AtomControllerButton | 3D print parts | 2 | JLCPCB | | 8 | Famicom button | Conductive rubber pad | 1 | Amazon | | 9 | SCREW 2.2 x 5.5 | Tapping screw | 3 | 秋月電子通商 | | 10 | PH-1X20SG | Pin header | 1 | 秋月電子通商 |
